Activated Carbon Fiber Recovery Device(ACF)

Application

  • Pesticide / Pharmaceutical / New Materials
  • New Energy Batteries & Materials
  • Packaging Printing / Coating

CADAIR offers high quality activated carbon fiber recovery devices, designed for industrial scenarios where pollutant gases are single-component, high-value, and high-concentration. These conditions are ideal for implementing circular economy strategies and reducing carbon emissions.

The system uses uniform porous activated carbon fiber to adsorb pollutants as a first step to meet emission standards. Then, through different heat sources (e.g. steam, hot air, hot nitrogen) and cooling equipment, the pollutants are desorbed and condensed.

Once condensed into liquid form, these pollutants are no longer waste — they become reusable raw materials of economic value. These substances can be directly reused or purified for recycling.

This recovery method not only brings direct economic return, but also provides an advantage in future carbon emission trading and carbon sink strategies, contributing to long-term environmental and market competitiveness.

Feature

  • Applicable air volume: 1,000~50,000 Nm³/h (single unit capacity)
  • Applicable concentration: 2,000~20,000 mg/Nm³
  • Recovery efficiency: 95~99.9%
  • The housing shell and skeleton are SUS304 / SUS316 / 2205 / TA… made
  • Full welding process to meet the air tightness test requirements
  • The inlet and outlet gas valves and purge valves are high temperature resistant and low leakage gas tight valves
  • Unique activated carbon fiber (ACF) material, less use, smaller equipment volume
  • Heat source standard steam type, hot nitrogen optional
  • Cold source with standard cooling water, chilled water, cold brine optional
  • After separation, the solvent can be distilled, distilled, and the resin dehydrated to improve the purity
  • The differential pressure meter can provide real-time feedback on the clogging status of ACF to guide maintenance replacement
  • The temperature instrument can feedback the temperature change of the suction and desorption condition in real time to guide the adaptive operation
  • The exterior of the box body can be equipped with climbing ladders, platforms and fences
  • For the occasion of compact site, 2 tower or rotary structure can be used
  • Split / skid loading
